TIME-Lab is equipped for almost all electromagnetic measurements, from DC up to 320 GHz.
- Network Analyzer: The lab possesses a range of network analyzers, including:
- Agilent E8364C (10MHz-50GHz PNA)
- Agilent N5242A (10MHz-26.5GHz PNA-X)
- Agilent N5260A Millimeter Head Controller
- Agilent 8720ES (50MHz-20GHz)
- HP 8722ET (50MHz-40GHz)
- Signal Generation: Signal generation capabilities include:
- HP 83640A (10MHz-40GHz Synthesized Sweeper)
- Keysight MXG Analog Signal Generator (9kHz-20GHz)
- Spectrum Analyzer: Spectrum analysis is supported:
- Agilent 8563EC (30Hz-26.5GHz)
- Agilent E4407B (9kHz-26.5GHz)
- Millimeter-Wave/THz Extension: The lab is equipped for mm-wave and THz measurements with:
- Agilent Harmonic Mixers (40GHz to 90GHz) compatible with Agilent 8563EC
- Agilent Frequency Multipliers (40GHz to 110GHz) model numbers 83556A, 85100V, 83558A compatible with HP 83640A
- OML Millimeter Wave VNA Extenders (140GHz to 220 GHz) model numbers V05VNA2-T/R and V05VNA2-T
- VDI Sub-Harmonic and Even Harmonic Mixers (WR-3.4: 220-320GHz)
- VDI Frequency Multipliers and Millimeter Wave Amplifiers (220-320GHz band)
- VDI PM5B Erickson Power meter (75 GHz to > 3 THz)
- Horn antennas and waveguide components for WR10, WR6.5, WR-5.1, WR-3.4 bands
- A wide range of components from Thorlabs and Edmund Optics for THz measurements
- Probing and Bonding: An Alessi probe station and Westbound wire-bonder facilitate device probing and interconnection.
- 3D Printing and Milling Tools: A Form 4 SLA 3D printer from Formlabs, equipped with a wide range of high-precision resins, along with a Bambu Lab H2D Pro 3D printer and an LPKF S103 milling machine, are used for sample prototyping.
- Optical Tables: Two optical tables (3′×3′ and 4′×6′) are available for optical experiments and setups.
